PVC wave roof tile production machine
Product features:
PVC+ASA glazed/corrugated hollow composite resin tile should be the IDEAL REPLACEMENT of conventional asbestos and metal G.I. sheets which are not resistant to corrosion and weather under the high cost and short service life.
This new PVC composite roof tile production adopted advanced multilayer CO-EXTRUSION technology which well combine the different functions of raw materials(PVC+ASA) so that the tile can be anti-corrosive, fire retardant, eco-friendly, more durable, tenacious, easy to install and move, light weight as well as cost effective in installation (as less steel and less overlap), as per the efficiency and benefits it provides.
Apart from its numerous benefits, its salient features include heat insulation up to 35% (highly energy efficient) and it can withstand temperature up to 70 degrees Celsius to – 40 degrees Celsius which is very much suitable for YOUR MARKET.
Product application: Plastic Corrugated tile are used for Roofing, can be used for factories, warehouses, sheds, farmers market, hoardings, walls, temporary shops, sheds and other very suitable insulation
MAIN PARAMETERS OF PVC WAVE ROOF TILE PRODUCTION MACHINE
| Sheet size | Width( mm) | 900 | 1130 | 1200 | 1300 |
| Thickness(mm) | 0.8-3 | 0.8-3 | 0.8-3 | 0.8-3 | |
| T-type Die head | Die head width | 1050mm | 1280 | 1350 | 1450 |
| Shape waves | Round waves or trapezoidal waves | ||||
| Max extruder | SJ-65/132 or 80/156 | SJ-80/156 | |||
| Max output | 250-300kg/h | 350-400kg/h | |||
| Drive motor | 37kw/55kw | 55kw/75kw | |||
